Product Features:
Technical Specifications:
- 100% pure-analog BBD chorus/pitch-vibrato effect
- Five simple controls:
- Wet/Dry (full 1:0 to 0:1 Dry/BBD mix control)
- Shine (gentle treble roll-off, -0.15dB to -5dB @ 1600Hz)
- Width (BBD modulation range/depth)
- Lag (base BBD delay: 4mS - 12mS)
- Rate (oscillaor rate)
- Extremely high-fidelity frequency response:
- Dry Freq. Response: 22KHz - 15Hz
- Wet (BBD) Freq. Response: 11.6KHz - 16Hz
- Very high headroom doubles as outboard/studio effect
- Digitally-controlled true analog-output waveform/modulation
- Full Wet/Dry mix control affords pure dry, to full-chorus, to true-pitch vibrato
- Easy to use tap-tempo with pulsing Real-Time LED indicator
- Wide LFO-rate range:
- 16.6Hz - 0.42Hz cycle (2.36S - 60mS)
- Up to 13 second (0.076Hz) cycle via tap-tempo foot-switch
- Four true-analog wave-forms (selected via Tap[Wave] foot-switch):
- Triangle
- Square
- Sine
- Glitch/Random
- Press-Hold for wave select/cycle
- Bi-Color Indicator/Status LED
- True-Bypass
Technical Specifications:
- Input Impedance: ~500KΩ
- Output Impedance: ~2KΩ
- 9VDC - 18VDC 2.1mm negative center-pin power
- ~62mA Current Draw
- Product dimensions:
- 3.97"W x 4.72"L x 2"H
- (101MM x 120MM x 51MM)
- Package dimensions:
- 4.65"W x 5.25"L x 2.15"H
- (118MM x 133MM x 55MM)
- Weight: 16 oz (454g)
